Item | Specifications | Note |
Material of housing | High-strength PP+GF | |
Material of internal components | High-strength ABS | |
Material of metal accessory | High-quality stainless steel | |
External dimension(mm) | 236mm x173mm x 80mm | |
Color | Black | |
Number of ports | 4 | |
Cable ports/Max.diameter of cable(mm) | 2 ports ,each port for 1 cable with max 16mm. 2 ports ,each port for 1 cable with max 13mm | |
Sealing type | Mechanical | |
IP grade | IP68 | |
Splicing capacity(Max) HTSC-154 | 4x12=48 | Optional as request |
