Item | Specifications | Note |
Material of housing | High-strength PC+ABS |
|
Material of internal components | ABS |
|
Material of metal accessory | High-quality stainless steel |
|
External dimension(mm) | 258*207*64 |
|
Color | Gray, black, white |
|
Number of distribution cable ports | 3 |
|
Number of drop cable ports | 12 |
|
3 Main Cable Ports | 2 cable gland, each port for 1 cable with max Ø 12mm. 1 reserved port for 1 cable with max Ø 12mm. |
|
Fiber cable dimension of drop port(mm) | φ3 |
|
Capacity(Max) | 24Splices |
|
Max quantity splitter | 1x4, 1x8 PLC splitter |
|
simplex adaptors | 12 |
|
IP grade | IP65 |
|
