Item | Specifications | Note |
Material of housing | High-strength PP+GF |
|
Material of internal components | High-strength ABS |
|
Material of metal accessory | High-quality stainless steel |
|
External dimension(mm) | 488*φ293 |
|
Color | Black |
|
Number of ports | 1 oval port, 16 round ports |
|
Fiber cable diameter of oval port (mm) | 12-30 mm |
|
Fiber cable dimension of round port (mm) | 7-20 mm |
|
Sealing type | Heat shrink sealing |
|
IP grade | IP68 |
|
Splicing capacity(Max) | 12x32=384F | Optional as request |
