Outside dimension (mm)
Φ230*345
Sealing type
Heat shrinkage
Number of inlet ports
1 oval port, 4 round ports
Diameter of optical loop cable (mm)
Φ9 - 22
Splicing capacity per splice tray
24
Max. number of trays
4
Max. splice capacity (single fiber)
96
IP Rank
IP68
Working temperature (℃)
-40 to +65℃
Insulation resistance
≥2X104MΩ
