Material of housing

High-strength PP+GF

Material of internal components

High-strength ABS

Material of metal accessory

High-quality stainless steel

External dimension(mm)

323mm x 202mm x 86mm

Color

Black

Number of ports

6

Cable ports/Max.diameter of

cable(mm)

6 ports. 2 large ports , each port

for 1 cable with max 20mm.

2 ports ,each port for 1 cable with

max 16mm.

2 ports ,each port for 1 cable with

max 13mm

Sealing type

Mechanical

IP grade

IP68

Splicing capacity(Max) HTSC-103

4x24=96

Optional as request

Splicing capacity(Max) HTSC-103

4*36=144
